GHL ION Director – Black

GHL ION DIRECTOR – BLACK

Fully Automatic Measurement and Control of Ca, Mg, K, Na, NO3

The ION Director (IOND for short) uses state-of-the-art ion-selective technology to automatically and accurately measure essential water parameters – calcium, magnesium, potassium, sodium, and nitrate with maximum comfort and affordable operating costs.

The precise and durable multi-ion sensor, specially developed by GHL for seawater analysis, requires no reagents, cost-effective reference liquids are used for the automatic calibration. Inaccurate, time-consuming, and costly measuring methods, such as test kits, are a thing of the past.

In addition to measurement, the ION Director System offers many other functions:

• Control: Automatic readjustment of dosing pumps to keep a value stable
• Monitoring: Alarm when the value is outside an adjustable range
• Analysis: Display in charts and logbook (via app, cloud and web server GHL Connect and GHL Control Center).

Combine the ION Director® with the KH Director® and measure and control the KH value in addition to Ca, Mg, K, Na and NO3.

ION Director Features

Unique multi-ion sensor
A compact and precise multi-ion sensor in laboratory-grade quality, specially developed by GHL for seawater analysis, which combines the functions of several sensors.

No reagent liquids required
There is no need for reagent liquids for measuring.

Precise measurement
Extreme accuracy due to special electronics, sensors and measuring algorithms developed and perfected by GHL.

Cost-effective and harmless reference liquid
Economical measurements due to low consumption and inexpensive reference liquids.

Adjustable measurements per day
The number of measurements per day can be set, additional measurements can be started manually at any time.

Automatic calibration
To achieve the maximum possible accuracy, a fully automatic calibration of the sensor is carried out before each measurement.

Measured-value history
Utilizing the measurement value history, you can interpret past measurement results and react to fluctuations.

Automatic adjustment of dosing amounts
In order to achieve stable water parameters, ION Director® can automatically readjust dosing quantities of supplied liquids depending on the measurement result.

LED Status Display
The LED-illuminated GHL logo conveniently provides color-coded status indicators. The various colors show you the condition of your system at a glance.

• White = Configuration mode
• Blue = Normal operation
• Green = Measurement or dosing in progress
• Yellow = Warning threshold – fluid container(s) are running low
• Red = Alarm threshold – fluid container(s) are empty

WiFi, App and much more
GHL devices offer the most connectivity options, you can choose between app, cloud, web interface or PC software via WiFi/LAN or USB.

Seamless integration in the GHL system
Through the use of the PAB (ProfiLux Aquatic Bus) connection, IOND seamlessly integrates into the modular GHL system. The PAB connection ensures interference free communication with other GHL PAB-devices such as the GHL Doser 2.1 or the ProfiLux® 4.

Low maintenance design
The multi-ion sensor is easily accessible thanks to the well-thought-out design of the ION Director® and can be easily cleaned or replaced if necessary.

Measured values always available from anywhere
Find out about measurement results at any time and from anywhere – via app, cloud, web server or Windows software. Display additionally values and states on the ProfiLux 3/4 display or ProfiLux Touch, if present.

Robust device in laboratory quality
The design of the ION Director® meets laboratory requirements. Like all our instruments, it is made of high quality materials to ensure a long service life.

Technical Specifications
ION Director® is available in two color options: Black or white
Dimensions (mm): 220 x 150 x 75 mm (w/out sensor)
Dimensions (in): 8.66″ x 5.9″ x 2.95″ (w/out sensor)

Scope of Delivery
ION Director® includes the following:

• Device with integrated measuring cell
• Multi-Ion sensor, especially designed for the IOND, incl. calibration liquids
• Silicone tube 5m
• Power-supply splitter-cable
